22IR 6ACME PT AC22R
Internal Right Hand ACME Partial Cresting Laydown Threading Inserts for Feed Screws
| Inscribed Circle Diameter (IC) | 1/2″ | Insert Style | Laydown (LT) |
| Insert Length (INSL) | 0.87″ | Cutting Direction (HAND) | Right Hand |
| Threads per Inch (TPI) | 6 Threads/" | Shape | 60° Triangle |
| Insert Thickness (S) | 0.252″ | Threads per Inch Minimum (TPIN) | 6 Threads/" |
| Cutting Width (CW) | 0.057″ | Threads per Inch Maximum (TPIX) | 6 Threads/" |
| Grade | AC22R | Tool Type | Threading Regular Inserts |
| Coating | TiAlN | Measurement Type | Inch |
| Cutting Edge Material | Carbide | Body Material | Carbide |
| Application | | Int Threading Laydown | | Unit | I |
| Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | |
Product Features
| Family Description | Internal Right Hand ACME Partial Cresting Laydown Threading Inserts for Feed Screws | FamilyName | IR-ACME-PT |
| COO | USA | BrandName | Tool-Flo |
Shipping Info
Weight per item
0.0004
Name
Laydown Threading Indexable Inserts
FamilyName
IR-ACME-PT
BrandName
Tool-Flo
