MTECB 0312C04 27NPT AC22
Solid Carbide Threading Endmills with Coolant Hole for External and Internal NPT Full Profile
| Thread Size | 1/8″ NPT | Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | |
| Threads per Inch (TPI) | 27 | Cutting Edge Material | Carbide |
| Connection Diameter Machine Side (DCONMS) | 0.313″ | Cutting Position | BOTH |
| Cutting Diameter (DC) | 0.299″ | Measurement Type | Inch |
| Overall Length (OAL) | 2-1/2″ | Grade | AC22 |
| Flute Count (NOF) | 3 | Depth of Cut Maximum (APMX) | 0.43″ |
| Coolant Supply Property (CSP) | Coolant Thru | Body Material | Carbide |
| Shank Type | Round | Connection Code Machine Side (CCMS) | Cylindrical |
| Coating | TiAlN | Thread Form Type (THFT) | NPT60 |
| Application | | External Thread Milling | Internal Thread Milling | | Unit | I |
Product Features
| Family Description | Solid Carbide Threading Endmills with Coolant Hole for External and Internal NPT Full Profile | COO | Israel |
Shipping Info
Weight per item
0.0002
