MTECB 1010D16 19BSPT AC22
Solid Carbide External or Internal Threading Endmills with Coolant Holes, for BSPT Thread Profile
| Thread Size | RC1/4-3/8 | Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | |
| Thread Pitch (TP) | 1.337 mm | Cutting Edge Material | Carbide |
| Threads per Inch (TPI) | 19 Threads/" | Measurement Type | Metric |
| Connection Diameter Machine Side (DCONMS) | 10 mm | Grade | AC22 |
| Cutting Diameter (DC) | 10 mm | Depth of Cut Maximum (APMX) | 16.7 mm |
| Overall Length (OAL) | 73 mm | Body Material | Carbide |
| Flute Count (NOF) | 4 | Connection Code Machine Side (CCMS) | Cylindrical |
| Shank Type | Round | Thread Form Type (THFT) | BSPT55 |
| Coating | TiAlN | Unit | M |
| Application | | External Thread Milling | Internal Thread Milling | |
Product Features
| Family Description | Solid Carbide External or Internal Threading Endmills with Coolant Holes, for BSPT Thread Profile | COO | Israel |
Shipping Info
Weight per item
0.0000
