| Cutting Width (CW) | 1/8″ | Application | | Int Ext Grooving Flo Lock | |
| Corner Radius (RE) | 0.062″ | Applicable Material | | Stainless Steel | Aluminum / Non-Ferrous Materials | Super-Alloys / Titanium | |
| Cutting Depth Maximum (CDX) | 0.29″ | Cutting Direction (HAND) | Right Hand |
| Insert Thickness (S) | 0.255″ | Measurement Type | Inch |
| Coating | Uncoated | Body Material | Carbide |
| Grade | C3 | Cutting Edge Length (L) | 0.633″ |
| Shape | Parrallelogram | Height | 0.453″ |
| Cutting Edge Material | Carbide | Unit | I |
Product Features
| Family Description | Internal and External Full Nose Radius Grooving #4 Gage FloLock Inserts with Right Hand Clamping Notch | FamilyName | FLR-4-RH |
| COO | USA | BrandName | Tool-Flo |
Shipping Info
Weight per item
0.0008
Name
Groove/Turn Indexable Inserts
FamilyName
FLR-4-RH
BrandName
Tool-Flo
