FLAS-3L4 PT-I AC50E
Partial-Topping Internal STUB ACME Profile Threading FloLock Inserts with Left Hand Clamping Notch
| Threads per Inch (TPI) | 4 | Cutting Edge Length (L) | 0.4″ |
| Application | | Int Threading Flo Lock | | Insert Size | 3 |
| Insert Thickness (S) | 0.344″ | Coating | TiAlN |
| Corner Radius (RE) | 0.01″ | Cutting Width (CW) | 0.1″ |
| Body Material | Carbide | Measurement Type | Inch |
| Number of Teeth | 1 | Unit | I |
| Grade | AC50E | Insert Width (W1) | 0.195″ |
| Cutting Direction (HAND) | Left Hand | Shape | Parrallelogram |
| Thread Pitch Maximum (TPX) | 0.344 mm |
