| Threads per Inch (TPI) | 28 | Insert to Shank Reference | 0.141″ |
| Application | | Int Ext Threading Flo Lock | | Cutting Edge Length (L) | 0.402″ |
| Insert Thickness (S) | 0.344″ | Insert Size | 3 |
| Corner Radius (RE) | 0.0059″ | Cutting Edge Material | Carbide |
| Body Material | Carbide | Coating | TiAlN |
| Applicable Material | | Steel | Stainless Steel | | Measurement Type | Inch |
| Number of Teeth | 1 | Thread Form Type (THFT) | UNJ Unified Nat. MIL-S-8879C |
| Grade | AC50C | Unit | I |
| Cutting Direction (HAND) | Left Hand | Insert Width (W1) | 0.195″ |
| Thread Pitch Maximum (TPX) | 0.344 mm | Shape | Parrallelogram |
