| Cutting Width (CW) | 0.189″ | Application | | Int Ext Face Grooving Flo Lock | |
| Insert Length (INSL) | 0.761″ | Depth of Cut Maximum (APMX) | 0.39″ |
| Corner Radius (RE) | 0.0225″ | Measurement Type | Inch |
| Cutting Depth Maximum (CDX) | 0.39″ | Coating | TiN |
| Insert Thickness Total (S1) | 0.453″ | Body Material | Carbide |
| Shape | Parrallelogram | Insert Thickness (S) | 0.255″ |
| Grade | GP3R | Unit | I |
| Cutting Direction (HAND) | Right Hand |
Product Features
| Family Description | Internal Face Deep Grooving #4 Gage FloLock Inserts with Right Hand Clamping Notch | FamilyName | FLFD-I-4-RH |
| COO | USA | BrandName | Tool-Flo |
Shipping Info
Weight per item
0.0008
Name
Face Groove/Turn Indexable Inserts
FamilyName
FLFD-I-4-RH
BrandName
Tool-Flo
